Mantis Overland

Name: Mantis Overland
Brand: TAXA Outdoors
SKU: VCL_MNTS_OL_WT
Availability: InStock

Starting at $49,749

Space to overland.

Build your Mantis Overland, get custom pricing, and reserve today for $250.

Click below to build your Mantis Overland, get custom pricing, and reserve today for $250.

Meet Mantis Overland.

With the Overland Edition of Mantis we took our most spacious habitat, full of thoughtfully designed features (like a 20-gallon fresh water tank, wet bath, full galley kitchen, and Truma furnace/hot water system), and added aspects like a Lock 'N' Roll hitch and a Timbren axle-less suspension with increased ground clearance enhancing Mantis’ go-anywhere durability.

Key Specs

Dry Weight: 3,486 lbs
14" Ground Clearance
Sleeps 4+ adults
Secure, pop-up roof for optimized ventilation

View all specs

Reserve Your Mantis Overland

With a $250 refundable deposit

1. Customize and place deposit

Build your vehicle by selecting preferred options and features. Add your $250 reservation deposit to the cart and finish checking out on our website.
2. Get matched with a dealer

After we received your deposit, a TAXA Adventure Specialist will reach out to confirm your reservation, set up priority placement with a nearby TAXA Dealer to fulfill your order.
3. Financing and fulfillment

Once you have been matched with a dealer, we’ll match you with financing options (if applicable) and oversee the final delivery of your adventure vehicle.

Reserve Now Get Financing

Image Gallery

Watch Video

Mantis Overland Features

Axle-Less Design

Progressive rubber springs and urethane bushings give the Overland Edition a ride that is quiet and smooth. Featuring a Timbren 5,200 lb Axle-Less trailer suspension with a 4″ lift allows you to go off road without the usual limitations associated with a thru-axle.

Lock 'N' Roll Hitch

The articulating Lock 'N' Roll hitch utilizes 360 degrees of rotation and 3 axis movement. This on-road, off-road hitch gives you freedom that you can’t get with a ball hitch.

All Terrain LT 225/75R16

The LT 225/75R16 tire is designed for those who need a tire that provides the rugged durability required to keep up with their active lifestyles. Engineered to tackle dirt, gravel, mud, and the urban jungle, this all terrain tire combines off-road prowess with agreeable on-road comfort and year-round traction, including in light snow.

Full Galley Kitchen

Durable baltic birch-wood cabinetry with high pressure laminate countertop. The galley kitchen includes a sink, two burner stove, an open shelving system, storage tower (with milk crate drawer system), cooler platform (with 12V outlet), and a 16 gallon trash can.

Adaptable Spaces

Spaces that easily transform and adapt to fit your life on the road. Convert the bed to a dinette, drop the bunk system into a couch and create room for the whole family (and then some!) to kick back when the weather calls for indoor time.

Premium Accessories

A collection of premium live-able accessories to make those long-haul trips as comfortable as you need them to be. From an integrated 12V electrical system, wet bath with a shower and cassette toilet, 8,000 BTU AC, furnace and hot water system, and a full galley kitchen, Mantis goes the distance.

Sleeping Space for 4+ Adults

Full/Queen size bed with access to 21 cubic feet of under bed storage comfortably sleeps two adults. The folding couch/bunk bed system adds sleeping space for two more adults. Add in a hammock or an optional rooftop tent and your sleeping capacity easily increases!

Full Features List

Powder-Coated Steel Chassis
1,500 lb Tongue Jack
Timbren Axle-Less Suspension with Electric Brakes
16" Alloy Wheel with All-Terrain Tires (60,000 mile manufacturer warranty)
16" Alloy Spare Wheel with All-Terrain Tire
Powder-Coated Steel Gravel Guards
Quad Stabilizer Jacks (Heavy Duty)
Laser Cut, Powder-Coated Steel Skeleton
Kynar-Painted Aluminum Composite Panels
Rear Hatch for Access & Ventilation
Pop-up Roof with Stainless Steel Scissor Hinge
Recycled Ripstop Polyester Tent Side with Four Mesh Windows
Six Acrylic, Insulated Windows with Screens & Shades
Roof Tracks for Rack Options
THULE® ProBar Evo 175 Adjustable Load Bars
Rear Ladder Steps to Roof Storage
23Zero 180° Peregrine "Batwing" Awning
20 Gallon Fresh Water Tank
22 Gallon Grey Water Tank
Exterior Hot & Cold Shower
Liquid Propane (2x 20 lb) Tanks with Cover
LED Exterior Lighting
Pre-Wired Solar Input
City Water Inlet
License Plate Bracket with LED Light
12V Accessory Outlet (Exterior)
Built in TAXA Bottle Opener
1" Plywood Deck with ABS Laminate
Non-Slip Seamless Nickel Patterned Flooring
8,000 BTU Air Conditioner (115V)
Baltic-Birch Plywood Kitchen with Milk Crate Drawer
High-Pressure Laminate Countertop
HDPE Countertop Behind Sink & Stove
2-Burner Stove with Hinged Lid
Sink with Hinged Lid
Truma® Combi Eco Furnace & Water Heater System
Two Storage Towers with Trio of Milk Crate Drawers
Raised Cooler or 12V Refrigerator Platform
16 Gallon Trash Can
Rotating/Nesting Cafe Table Top (33" x 19") with Aluminum Pedestal
Full Size Bed with Under Bed Storage (21 Cubic Feet)
Folding Couch / Bunk Bed System (with bunk net)
LED Interior Lighting with Reading Lights
12V Digital Voltmeter
12V Accessory Outlets (Interior)
12V USB Outlets (Interior)
Battery Compartment (Fits 2 Group 24 or Group 27 Batteries.)
2x Deep Cycle AGM Batteries
Entry Screen Door
Victron 75/15 SmartSolar Bluetooth Charge Controller
WFCO 40 Amp Auto-Detect Power Center to Accommodate Lithium Batteries
Portable Fridge/Freezer Combo | ICECO VL45Pro 47.5QT

View Mantis Overland Specs

Mantis Overland Specs*

Exterior Width	7'6"
Exterior Length	19'
Dry Weight (including standard features only)	3,486 lbs
Exterior Height (closed)	7'
Exterior Height (open)	10'1"
Interior Width (max)	6'10"
Interior Height (closed)	4'7"
Interior Height (open)	5'11" to 7'10"
Bed Dimensions (max width)	80" x 54"
Fresh Water Tank	20 gal
Grey Water Tank	22 gal
Tires	225/75R16
Ground Clearance	14"
Tongue Weight (depends on load)	510 lbs
Tongue Length	45"
Tongue Height	22"
GVWR	5,000 lbs
GAWR	5,200 lbs
Capacity	4+ Adults
Cargo Capacity	1,614 lbs
Aluminum Panels	Aluminum Alloy ASTM B 209
Bunk Bed (top)	76" x 22"
Bunk Bed (bottom)	77" x 26"
